BAHA Procedure

BAHA Procedure

  • Marking
  • Baha procedure marking

  • Measuring the skin flap thickness with needle
  • Baha procedure measuring

  • Drilling
  • Baha procedure drilling

  • Titanium screw is inserted with the inserter drill using the torque of 30 to 50 Nm depending upon the softness of the bone
  • Baha procedure magnet

  • Magnet is placed and then tightened with the micro-screw driver and it is hen tightened with the torque wrench
  • Baha procedure screwing driver

  • Skin flap thickness is measured and if required flap is thinned down
  • Baha procedure flap

  • Incision is than closed in layers and sterile bandage is applied.
